DVD DECK REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
! 600 AE006521 A2F401H650 DVD MECHA ASS'Y A2F401H650
601 AE005003 92P100109A HOLDER,TRAVERSE
602 AE003550 92P100094A CLAMPER
603 AE003551 92P100088A GEAR,MOTOR
604 AE005414 92P100108A GEAR,MIDDLE
605 AE003538 92P200013A INSULATOR(F)
606 AE003539 92P200014A INSULATOR(R)
607 AE006115 92SBB0029A LOADER SUB ASS'Y
608 AE003541 92P100095A GEAR,PULLEY
609 AE003542 92P100097A PULLEY,MOTOR
610 AE003549 92P100096A GEAR,MAIN
611 AE003544 92P200012A BELT,LOADING
612 AE003545 92P000014A PLATE,CLAMPER
613 AE003546 92P100093A RACK,LOADING
614 AE003547 92P100091A FRAME,MAIN
615 AE003548 92P100092A TRAY
616 BZ710149 800WFAA008 CUSHION C
701 AE003530 811022680U SCREW,TAP TITE(P) BIND 2.6x8
702 AE003554 814011723U SCREW,PAN M1.7x2.3 P3
703 AE003555 816112080U SEMS.TAP TITE(P) PAN W10 2x8
704 AE003556 814011730U SCREW,PAN M1.7x3 P3
705 AE003557 811022080U SCREW,TAP TITE(P) BIND 2x8
CD2001 AD301855 122H0O1901 CORD JUMPER 2H0O1901
CD2301 AE003558 122H062102 CORD JUMPER 2H062102
CD2302 AE003559 122H052601 CORD JUMPER 2H052601
! M2602 AE005930 1515S98003 FEED MOTOR BCZ3B03B
! M2603 AE005931 1596S18003 MOTOR,LOADING BCZ3B52B
PCB610 AE005932 A5R801V610 PCB ASS'Y DED003A
PCB640 AE006740 A2F401H640 PCB ASS'Y DED012B
SW1 AE003564 0515S32002 SWITCH SSS-13-2
SW2 AE003565 0500101037 PUSH SWITCH ESE22MH24
J3-1
