Toshiba MW24F11 Service Manual

600
DVD DECK EXPLODED VIEW
I3-1
610
608
M2603
704
612
614
615
613
602
609
611
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
Do not replace the parts. Because,
minute adjustments are needed if
this condition is disassembled
further more.
If the repair is needed, replace the
DVD MECHA ASS'Y.
M2602
603
601
605
605
606
702
703
SW1
PCB610
(LOADING MOTOR PCB ASS'Y)
CD2302
701
607
CD2001
604
SW2
PCB640
(SW PCB ASS'Y)
CD2301
705
Cannot supply separately.
If the repair is needed, replace the
LOADER SUB ASS'Y.
Applying positions AA for the grease are displayed for this section.
Check if the correct grease is applied for each position.
NOTE:
CLASS
GREASE
MARK
AA
616
