ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R401 BZ210258 R4X5T6472F R,METAL 4.7K OHM 1/6W

! R403 BZ210105 R4X5T6183F R,METAL 18K OHM 1/6W

! R405 BZ210231 R4X5T6153F R,METAL 15K OHM 1/6W

! R406 BZ210280 R3X28A391J R,METAL OXIDE 390 OHM 2W

! R412 AE006490 R63881330J R,FUSE 33 OHM 1W

! R417 BZ210262 R3X28A221J R,METAL OXIDE 220 OHM 2W

! R423 BZ210051 R3X18AR47J R,METAL OXIDE 0.47 OHM 2W

! R429 BZ210053 R002T22R2J RC 2.2 OHM 1/2W

! R430 AD301920 R5X34F2R7J R,CEMENT 0 2.7 OHM 10W

! R434 BZ210130 R002T21R5J RC 1.5 OHM 1/2W

R435 AD301595 R65582010J R,FUSE 1 OHM 1/2W

R436 BZ210277 R3X181101J R,METAL OXIDE 100 OHM 1W

! R440 AD301921 R5X34F332J R,CEMENT 0 3.3K OHM 10W

! R445 AE003270 R3X28B2R7J R,METAL OXIDE 2.7 OHM 3W

! R454 BZ210003 R3K181102J R,METAL OXIDE 1K OHM 1W

! R814 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R815 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R816 BZ210050 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R1701 BZ210206 R002T2155J RC 1.5M OHM 1/2W

! R1702 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W

! R1714 BZ210268 R3X181R12J R,METAL OXIDE 0.12 OHM 1W

! R1717 BZ210249 R3X28A331J R,METAL OXIDE 330 OHM 2W

! R1718 BZ210031 R5X2CE1R2J R,CEMENT 1.2 OHM 7W

! R1720 AE005735 R63881R22J R,FUSE 0.22 OHM 1W

R3010 AD302206 R3X181180J R,METAL OXIDE 18 OHM 1W

R3021 AE000147 R3X181220J R,METAL OXIDE 22 OHM 1W

R3028 BZ210204 R3X1814R7J R,METAL OXIDE 4.7 OHM 1W

CAPACITORS

C005 BZ110154 E02L00102M CE 1000 UF 6.3V

C321 BZ210176 E02LF3222M CE 2200 UF 25V

! C403 BZ110195 E02LU8220M CE 22 UF 100V

C404 AE004798 E61DFB470M CE 47 UF 160V

! C408 BZ110233 P4N8FK332H CMPP 0.0033UF 1.5KV

! C412 BZ210173 P4J7F3474J CMPP 0.47 UF 250V PMS

! C417 BZ110054 P3N1F5333J CPP 0.033 UF 630V

! C418 AD302207 P4N8FK153H CMPP 0.015 UF 1.5KV

! C429 AD301434 E02LU4101M CE 100 UF 35V

! C430 BZ110101 E5EZF3222M CE 2200 UF 25V

C432 AE000745 E52H02470M CE 47 UF 16V

! C434 BZ110055 E5EZF4102M CE 1000 UF 35V

C435 AE006084 E736F56R8M CE 6.8 UF 50V

! C446 BZ110225 E5EZFD220M CE 22 UF 250V

C449 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

C820 BZ110247 C0JBB0713K CC 0.001 UF 2KV B

! C1701 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL

C1705 BZ110183 C03L0R7W2K CC 820 PF 2KV R

C1707 BZ110202 C0PLRR713K CC 0.001 UF 2KV R

! C1708 BZ110226 C0JBB07H3K CC 0.0022UF 2KV B

! C1710 BZ110226 C0JBB07H3K CC 0.0022UF 2KV B

! C1711 AE002878 CD39E0MQ3M CC 0.0047UF 250V

! C1714 AE000700 E52DHC681M CE 5 680 UF 200V

C1716 BZ110010 E02L03222M CE 2200 UF 25V

! C1717 BZ110055 E5EZF4102M CE 1000 UF 35V

! C1720 AE006083 E61DFB221M CE 220 UF 160V

C1725 AE000074 E02L08101M CE 100 UF 100V

! C1728 AD300511 E02LT0222M CE 2200 UF 6.3V

C1729 BZ110176 C03L0R7Q2K CC 470 PF 2KV R

C1732 BZ110032 E5EZF3102M CE 1000 UF 25V

C3010 AE000744 E02L00222M CE 2200 UF 6.3V

DIODES

D101 AD301638 0010E00330 INFRARED LED LTE-3271T-012A-O

D102 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D103 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D105 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D106 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D108 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D402 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D403 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D404 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D405 BZ410117 D2BFRS4FS0 DIODE,SILICON RS-4FS

! D406 BZ410118 D2BFRU4AM0 DIODE,SILICON RU-4AM
