210 P9 ASD Installation and Operation Manual
Display Bias
Program Utilities Display Parameters
In conjunction with the setting of F702, this parameter sets the bias of the EOI
speed display.
The frequency entered here will be multiplied by the setting of F702 and then
displayed as the zero value on the EOI display.
Direct Access Number — F706
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — Yes
Minimum — 0.00
Maximum — Maximum Freq. (F011)
Units — Hz
Change Step Selection 1
Program Utilities Display Parameters
In conjunction with the setting of F708, this parameter sets the amount that the
output speed will increase or decrease for each speed command change entered
from the EOI using the Rotary Encoder.
Direct Access Number — F707
Parameter Type — Numerical
Factory Default — 0.00
Changeable During Run — Yes
Minimum — 0.00
Maximum — Maximum Freq. (F011)
Units — Hz
Change Step Selection 2
Program Utilities Display Parameters
The parameter is used to modify the degree that the setting of F707 affects the
output speed changes that are input from the EOI using the Rotary Encoder.
Selecting a zero value here disables this parameter and the resulting non-zero
value of parameter setting
F707 is output from the ASD.
Selecting a non-zero value here provides a dividend that will be used in the
following equation resulting in the actual output frequency applied to the motor.
Direct Access Number — F708
Parameter Type — Numerical
Factory Default — 0 (Disabled)
Changeable During Run — Yes
Minimum — 0
Maximum — 255
Operation Command Clear Selection When ST Off
Program Special  Operation Panel Parameters
Upon deactivation of the ST terminal while operating in the Hand mode, the
ASD output to the motor will cease — this parameter setting is used to allow
for the reactivation of the motor without user intervention upon the reactivation
of the ST terminal.
Upon reactivation of the ST terminal in this condition, the ASD will resume the
Run condition and the motor will start (1 — Retain Run Command).
This feature may be Disabled and the Run command must be re-initiated by the
user for ASD operation (0 — Clear Panel Run Command).
WHEN ENABLED THE ASD WILL RESUME THE RUN CONDITION
WHEN THE ST TERMINAL IS REACTIVATED.
Settings:
0 — Clear Panel Run Command
1 — Retain Panel Run Command
Direct Access Number — F719
Parameter Type — Selection List
Factory Default — Retain Panel Run
Command
Changeable During Run — Yes
OutputFrequencyDisplayed InternallyCommandedFrequency
F708
F707
-------------=
DANGER
F706 F719
