U
TILITIES
Trip History (read-only)
Dynamic Braking Resistor (DBR) Load
N/A
Input Power
Output Power
Changed From Default
Display Changed Parameters N/A
Contrast
Contrast Adjustment N/A
Main Monitor
Selections
Monitor 1
N/A
Monitor 2
Trace
Trace Selection F740
Trace Cycle F741
Trace Data 1 F742
Trace Data 2 F743
Trace Data 3 F744
Trace Data 4 F745
View Trace Data
View Trace Data
N/A
Save/Restore Wizard
Save/Restore System Settings
P
ROTECTION
Protection
Abnormal Speed
Settings
Abnormal Speed Detection Time F622
Over-Speed Detection Frequency Upper Band F623
Over-Speed Detection Frequency Lower Band F624
Base Frequency
Voltage
Supply Voltage Correction F307
DC Injection Braking
DC Injection Braking Start Frequency F250
DC Injection Braking Current F251
DC Injection Braking Time F252
Forward/Reverse DC Injection Braking Priority F253
Motor Shaft Stationary Control F254
Dynamic Braking
Dynamic Braking Selection F304
Dynamic Braking Resistance F308
Continuous Dynamic Braking Capacity F309
Braking Resistance Overload Time (10x Rated Torque) F639
Emergency Off
Settings
Emergency Off F603
Emergency DC Injection Braking Control Time F604
Program Mode Menu Navigation
Primary Menu Sub Menu Parameter Name
Parameter
Number
ontras
