6F3B0250
Basic Hardware and Function
15
1. System Configuration
Memory capacity:
Program memory capacity of the T1 is 2 k steps. And that of the T1S is 8 k steps. Whole
the program and a part of data registers are stored in built-in EEPROM.
T1 T1S
Memory
RAM (for execution) and EEPROM (for back-up)
Program capacity
2 k steps 8 k steps
(4 k mode or 8 k mode)
Data capacity
Auxiliary relay: 1024 points
Timer: 64 points
Counter: 64 points
Data register: 1024 words
Auxiliary relay: 4096 points
Timer: 256 points
Counter: 256 points
Data register: 4096 words
EEPROM back-up
Program and leading 512 words
of Data register
Program and the user specified
range of Data register (0 to
2048 words)
RAM back-up
Capacitor
(6 hours or more at 25
°
C)
Capacitor
(168 hours or more at 25
°
C)
Control functions:
In addition to the basic relay ladder functions, the T1/T1S provides functions such as
data operations, arithmetic operations, various functions, etc. Furthermore, its high
speed counter functions, pulse output functions and data communication functions
allow its application to a wide scope of control systems.
T1 T1S
Language
Ladder diagram with function block
Number of
instructions
Basic: 17 types
Function: 76 types
Basic: 21 types
Function: 99 types
Subroutines
16 (nesting not allowed) 256 (up to 3 levels of nesting)
Execution speed
1.4
m
s/contact, 2.3
m
s/coil, 4.2
m
s/transfer, 6.5
m
s/addition
Real-time clock/
calendar
No Yes (year, month, day, week,
hours, minutes, seconds)
Communication
RS-232C (programmer port) RS-232C (programmer port),
RS-485 (multi-purpose)
Construction:
The T1/T1S is a compact, easy-handling block style programmable controller. The
T1/T1S has all of the features of a block style controller. In addition, the T1-40/T1-40S
has modular expandability. The T1-40/T1-40S provides flexibility into the block style
controller.
Series compatibility:
Programming instructions are upward compatible in the T-Series programmable
controllers. The T1/T1S programs can be used for other models of the T-Series, T2,
T2E, T2N, T3 and T3H. Peripheral tools can also be shared.
