306
T1/T1S User’s Manual
Appendix
A.1 List of models and types
·
··
·
Basic unit
Model Power supply Input type Type code Part number
T1-16 100 - 240 Vac Dry contact T1-MDR16
TDR116*6S
120 Vac T1-MAR16
TAR116*6S
24 Vdc 24 Vdc T1-MDR16D
TDR116*3S
T1-28 100 - 240 Vac 24 Vdc T1-MDR28
TDR128*6S
120 Vac T1-MAR28
TAR128*6S
24 Vdc 24 Vdc T1-MDR28D
TDR128*3S
T1-40 100 - 240 Vac 24 Vdc T1-MDR40
TDR140*6S
120 Vac T1-MAR40
TAR140*6S
24 Vdc 24 Vdc T1-MDR40D
TDR140*3S
T1-40S 100 - 240 Vac 24 Vdc T1-MDR40S TDR140S6S
120 Vac T1-MAR40S TAR140S6S
24 Vdc 24 Vdc T1-MDR40SD TDR140S3S
·
··
·
Option card
Description Type code Part number
16 points 24 Vdc input DI116
TDI116*BS
16 points 24 Vdc output DO116
TDO116*BS
8 points 24 Vdc input and 8 points 24 Vdc output DD116
TDD116*BS
2 channels analog input, 0 - 5 V/0 - 20 mA AD121
TAD121*BS
2 channels analog input, ±10 V
AD131
TAD131*BS
2 channels analog output, 0 - 20 mA DA121
TDA121*BS
2 channels analog output, ±10 V
DA131
TDA131*BS
TOSLINE-F10 remote station FR112
TFR112*BS
·
··
·
Expansion unit
Description Type code Part number
16 points 24 Vdc input and 16 points relay output
(with 0.5 m cable)
T1-EDR32
TDR132E*S
16 points 120 Vac input and 16 points relay output
(with 0.5 m cable)
T1-EAR32
TAR132E*S
·
··
·
Expansion rack
Description Type code Part number
2-slot for T2 I/O modules (with 0.15 m cable) BU152
TBU152**S
4-slot for T2 I/O modules (with 0.15 m cable) BU154
TBU154**S
