Toshiba PROSEC T1 - Page 25

6F3B0250
Basic Hardware and Function
23
1. System Configuration
¨
¨¨
¨
T1-16
¨
¨¨
¨
T1-28
PROSEC
T1
TOSHIBA
MDR16
OUT
IN
PROSEC
T1
MDR28
OUT
IN
TOSHIBA
Power supply and
Input terminals
Input status LEDs
Output status LEDs
Mounting hole
Programmer port cover
Output terminals
Operation status LEDs
Power supply and
Input terminals
Input status LEDs
Mounting
hole
Output terminals
Output status LEDs
Programmer
port cover
Operation status LEDs
