User’s Manual 1-3
Introduction
Hardware
This section describes the hardware of your computer.
The actual specifications may vary depending on the model you
purchased.
Processor
Memory
Built-in The computer is equipped with one of the
following Intel
®
processor.
■ Intel
®
Core
TM
2 Duo Processor, which
incorporates a 3MB level2 cache memory
and also supports Enhanced Intel
SpeedStep
®
Technology.
■ Intel
®
Core
TM
2 Duo Processor, which
incorporates a 6MB level2 cache memory
and also supports Enhanced Intel
SpeedStep
®
Technology.
Some models in this series use Intel
®
Centrino
®
2 processor technology
which is based on three separate components, the Intel
®
Core
TM
2 Duo
processor, Intel
®
Wi-Fi
®
Link 5300AGN -OR- 5100AGN and the Intel
®
GM/PM45 Express Chipset.
Legal Footnote (CPU)*1
For more information on the CPU, please refer to the Legal Footnotes
section in Chapter 11 or Click the *1 above.
Memory slots 512, 1,024 or 2,048MB memory modules can be
installed in the computer's two memory slots for a
maximum of 4,096MB system memory.
This computer can be equipped with memory
modules of a maximum size of 4,096MB. The
actual amount of useable system memory will be
less than the installed memory modules.
