User’s Manual 2-1
Chapter 2
The Grand Tour
This chapter identifies the various components of the computer - it is
recommended that you become familiar with each before you operate the
computer.
Front with the display closed
The following figure shows the computer’s front with its display panel in the
closed position.
Figure 2-1 Front of the computer with display closed
Legal Footnote (Non-applicable Icons)*8
For more information regarding Non-applicable Icons, please refer to the
Legal Footnotes section in Chapter 11 or click the *8 above.
Please handle your computer carefully to avoid scratching or damaging the
surface.
Optical disc drive
Infrared receiver window
Wireless communication switch
Optical disc drive The computer is configured with a DVD Super
Multi drive.
