Appendices Apx. C Pin Assignments
C-28 Satellite M40/M45 TECRA A4 dynabook VX/4 Maintenance Manual
35 IDE_3S_D(11) I/O 36 IDE_3S_D(4) I/O
37 IDE_3S_D(10) I/O 38 IDE_3S_D(5) I/O
39 IDE_3S_D(9) I/O 40 IDE_3S_D(6) I/O
41 IDE_3S_D(8) I/O 42 IDE_3S_D(7) I/O
43 GND - 44 IDE_RST# O
C.25 CN515 PCMCIA Card Connector (68-Pin)
Table C-25 PCMCIA Card Connector pin assignment (68-Pin)(1/2)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 GND - 2 ACARD_3S_AD0 I/O
3 ACARD_3S_AD1 I/O 4 ACARD_3S_AD3 I/O
5 ACARD_3S_AD5 I/O 6 ACARD_3S_AD7 I/O
7 ACARD_3S_CBE0# I/O I8 ACARD_3S_AD9 I/O
9 ACARD_3S_AD11 I/O 10 ACARD_3S_AD12 I/O
11 ACARD_3S_AD14 I/O 12 ACARD_3S_CBE1# I/O
Table C-25 PCMCIA Card Connector pin assignment (68-Pin)(2/2)
13 ACARD_3S_PAR I/O 14 ACARD_3S_PERR# I/O
15 ACARD_3S_GNT# I/O 16 ACARD_3S_INT# I/O
17 ACARDVCC - 18 ACARDVPP -
19 ACRD_3S_CLK I/O 20 ACARD_3S_IRDY# I/O
21 ACARD_3S_CBE2# I/O 22 ACARD_3S_AD18 I/O
23 ACARD_3S_AD20 I/O 24 ACARD_3S_AD21 I/O
25 ACARD_3S_AD22 I/O 26 ACARD_3S_AD23 I/O
27 ACARD_3S_AD24 I/O 28 ACARD_3S_AD25 I/O
29 ACARD_3S_AD26 I/O 30 ACARD_3S_AD27 I/O
31 ACARD_3S_AD29 I/O 32 ACARD_3S_D(2)_RFU I/O
33 ACARD_3S_CLKRUN#
I/O 34 GND -
35 GND - 36 ACARD_3S_CD1# I/O
37 ACARD_3S_AD2 I/O 38 ACARD_3S_AD4 I/O
39 ACARD_3S_AD6 I/O 40 ACARD_3S_D(14)_RFU
I/O
41 ACARD_3S_AD8 I/O 42 ACARD_3S_AD10 I/O
43 ACARD_3S_VS1# I/O I44 ACARD_3S_AD13 I/O
45 ACARD_3S_AD15 I/O 46 ACARD_3S_AD16 I/O
47 ACARD_3S_A18_RFU
I/O 48 ACARD_3S_BLOCK# I/O
49 ACARD_3S_STOP# I/O 50 ACARD_3S_DEVSEL# I/O
To Next Page
