INTERFACE MANUAL
Table 4.1 List of system input signal ON modes
Master mode ON mode
EXTERNAL
Designation TEACHING INTERNAL EXT. SIGNAL EXT. HOST
STROBE (Strobe)
O
PRG_RST (Program reset)
O
STEP_RST (Step reset)
O
CYC_RST (Cycle reset)
O
DO_RST (Output signal reset)
O
ALM_RST (Alarm reset)
O
RUN (Start)
O
EX_SVON (External servo ON)
O
STOP (Stop) O O O O
CYCLE (Cycle operation mode)
O
LOW_SPD (Low speed command) O O O O
BREAK (Deceleration and stop) O O O O
SVOFF (Servo OFF) O O O O
EMS*B ~ EMS*C (Emergency stop
contacts 1 and 2)
O
O O O
O : ON mode
Designation STROBE (Strobe)
Input terminal CN5–13 pin
Exclusive signal
name used in the
controller
249
Signal logic
Signal judgment
Signal terminal
ON OFF
Open
O
Short-circuit O
STE 71367
– 40 –
