INTERFACE MANUAL
• Output circuit structure
When Type N is selected (when X8HN printed board is used)
(1) Transistor output (2) Relay contact output
* The above figure exemplifies a
normal open contact output
structure.
The servo ON contact output is of a
normal open contact type and the
emergency stop contact output is of
a normal close contact type. Take
utmost care when using.
User side
P24V
●
P24G
[ Sink type ("-" common) ]
User side
External
power
supply
Type N
STE 71367
– 66 –
