6.3 RAS Information Read Data
6
6.3 RAS Information Read Data
This section describes the RAS information of the DN311 (RAS counter, event history,
executing node information) read by the ladder program. See 4.3.6 RAS Information read
request for details on this request.
6.3.1 RAS Counter
When request information type 1 is set for RAS information read request, the RAS
counter can be read into the acknowledgement area.
Acknowledgement Area
0660H Request code (0015H)
0661H Completion status
0662H Number of RAS information
words
100 words
0663H RAS counter
:
:
Table 6-4 RAS Counter List (ÇP/ÇR)
Symbol name Address Description
RAS_CNT[0] 0663H Abnormal interrupt (intret)
RAS_CNT[1] 0664H Abnormal interrupt (trap)
RAS_CNT[2] 0665H Number of host interrupts
RAS_CNT[3] 0666H Number of port request interrupts
RAS_CNT[4] 0667H Number of receive response interrupts
RAS_CNT[5] 0668H Receive response ID error
RAS_CNT[6] 0669H Receive response request code invalid
RAS_CNT[7] 066AH Number of port requests accepted
RAS_CNT[8] 066BH Number of times other than port request register ON
RAS_CNT[9] 066CH Number of port memory pool errors
RAS_CNT[10] 066DH Memory pool error status code
RAS_CNT[11] 066EH Number of reset requests
RAS_CNT[12] 066FH Reset response
RAS_CNT[13] 0670H Number of parameter requests
RAS_CNT[14] 0671H Number of parameter responses
RAS_CNT[15] 0672H Number of control requests
RAS_CNT[16] 0673H Number of control responses
RAS_CNT[17] 0674H Number of RAS read requests
RAS_CNT[18] 0675H Number of RAS read responses
RAS_CNT[19] 0676H Number of time setting requests
RAS_CNT[20] 0677H Number of time setting responses
RAS_CNT[21] 0678H Number of input data read requests
RAS_CNT[22] 0679H Number of input data read responses
