6F8C0903
123
6.3 RAS Information Read Data
6
6.3.3 Execution node information
When request information type 3 is set for RAS information read request, slave device
execution information (module status and 7-segment LED status indications) can be read
into the acknowledgement area.
Acknowledgement Area
(1) Module Status (0663H to 0682H: 32 words)
The 0663H to 0682H in the acknowledgement area represent module status. Module
status indicates in code the operations of the DN311 for the slave devices and the
network. "NA = [ ]" in Table 6-6 shows a node address.
0660H Request code (0015H)
0661H Completion status
0662H Number of RAS information
words
64 words
0663H Execution node information
:
06A2H
Table 6-6 Module Status
F 8 7 0 F 8 7 0
0663H NA=1 NA=0 0673H NA=33 NA=32
0664H NA=3 NA=2 0674H NA=35 NA=34
0665H NA=5 NA=4 0675H NA=37 NA=36
0666H NA=7 NA=6 0676H NA=39 NA=38
0667H NA=9 NA=8 0677H NA=41 NA=40
0668H NA=11 NA=10 0678H NA=43 NA=42
0669H NA=13 NA=12 0679H NA=45 NA=44
066AH NA=15 NA=14 067AH NA=47 NA=46
066BH NA=17 NA=16 067BH NA=49 NA=48
066CH NA=19 NA=18 067CH NA=51 NA=50
066DH NA=21 NA=20 067DH NA=53 NA=52
066EH NA=23 NA=22 067EH NA=55 NA=54
066FH NA=25 NA=24 067FH NA=57 NA=56
0670H NA=27 NA=26 0680H NA=59 NA=58
0671H NA=29 NA=28 0681H NA=61 NA=60
0672H NA=31 NA=30 0682H NA=63 NA=62
Table 6-7 Module Status Codes
Module Status Code Description
0 (00H) Normal status
1 (01H) Transmission not enabled
2 (02H) No data flow in the transmission line
3 (03H) Communication error
4 (04H) Scan list disagrees with the actual slave composition.
5 (05H) Network error
6 (06H) Network power error detected.
9 (09H) Busoff detected.
10 (0AH) Duplicate node address detected.
To Next Page
