Appendix C Definition of Each
Request Function Block
C.1 Reset Request Function Block
(1) Definitions of Variables
(*===================================================
DeviceNet FB Reset Request
===================================================*)
VAR_INPUT
REQ: BOOL; (*Execution request*)
CH: WORD; (*Channel specify*)
UNIT: WORD; (*Unit specify*)
SLOT: WORD; (*Slot specify*)
CLR_SL: WORD; (*Scan list clear*)
END_VAR
VAR_OUTPUT
DONE: BOOL; (*Completion*)
ERR: BOOL; (*Error*)
STATUS: WORD; (*Status*)
END_VAR
VAR_EXTERNAL
SW: ARRAY[0...511] OF INT; (*SW register INT access*)
END_VAR
VAR
SLOTNO: WORD; (*R/W slot number*)
TMP_CH: WORD; (*R/W channel number*)
TMP_UNIT: WORD; (*R/W unit number*)
TMP_CHUNIT: WORD; (*R/W channel/slot numbers*)
S3: BOOL; (*S3 selection*)
S2: BOOL; (*S2 selection*)
STEP: ARRAY [0...9] OF BOOL; (*Step*)
DEF1: BOOL; (*Differential contact*)
DUMMY_W1: BOOL; (*Dummy*)
ADR_WRT1: WORD; (*Extension memory address*)
DAT_WRT1: ARRAY[0...1] OF WORD; (*Transfer source variable*)
NUM_WRT1: UINT; (*Number of words to transfer)
DUMMY_W2: BOOL; (*Dummy*)
ADR_WRT2: WORD; (*Extension memory address*)
DAT_WRT2: WORD; (*Transfer source variable*)
