202

model 3000 DeviceNet Module Manual (DN311/DN311A)

Appendix D Definitions of the Function Block for Slave Data Input/Output

S3: BOOL; (*S3 selection*)

S2: BOOL; (*S2 selection*)

STEP: ARRAY [0...4] OF BOOL; (*Step*)

DEF1: BOOL; (*Differential contact*)

DUMMY_11: BOOL; (*Dummy*)

DUMMY_12: BOOL; (*Dummy*)

DUMMY_R1: BOOL; (*Dummy*)

ADR_RED1: WORD; (*Extension memory address*)

DAT_RED1: ARRAY[0...9] OF UINT; (*Transfer destination variable*)

TMP1: ARRAY[0...5] OF UINT; (*Address calculation data*)

TMP2: ARRAY[0...11] OF UINT; (*Address calculation data*)

TMP3: ARRAY[0...5] OF UINT; (*Address calculation data*)

TMP4: UINT; (*Address calculation data*)

NEXT: BOOL; (*Next step*)

NEXT2: BOOL; (*Next step*)

TMR1: TON_100ms; (*Error detection timer*)

TIME1: DINT; (*Error detection time*)

DUMMY_R2: BOOL; (*Dummy)

ADR_RED2: WORD; (*Extension memory address*)

DAT_RED2: WORD; (*Transfer destination variable*)

NUM_RED2: UINT; (Words to transfer*)

END_VAR
