4.2 S Controller Interface Buffer Memory Configuration
4
(6) Slave device configuration information (05A6H to 05C5H: 32 words)
This area shows the scan type information on slave devices is set in the DN311
(stored in the non-volatile memory).
Table 4-7 Slave Device Configuration Information
Address F870
05A6H Node address: 1 Node address: 0
05A7H Node address: 3 Node address: 2
05A8H Node address: 5 Node address: 4
05A9H Node address: 7 Node address: 6
05AAH Node address: 9 Node address: 8
05ABH Node address: 11 Node address: 10
05ACH Node address: 13 Node address: 12
05ADH Node address: 15 Node address: 14
05AEH Node address: 17 Node address: 16
05AFH Node address: 19 Node address: 18
05B0H Node address: 21 Node address: 20
05B1H Node address: 23 Node address: 22
05B2H Node address: 25 Node address: 24
05B3H Node address: 27 Node address: 26
05B4H Node address: 29 Node address: 28
05B5H Node address: 31 Node address: 30
05B6H Node address: 33 Node address: 32
05B7H Node address: 35 Node address: 34
05B8H Node address: 37 Node address: 36
05B9H Node address: 39 Node address: 38
05BAH Node address: 41 Node address: 40
05BBH Node address: 43 Node address: 42
05BCH Node address: 45 Node address: 44
05BDH Node address: 47 Node address: 46
05BEH Node address: 49 Node address: 48
05BFH Node address: 51 Node address: 50
05C0H Node address: 53 Node address: 52
05C1H Node address: 55 Node address: 54
05C2H Node address: 57 Node address: 56
05C3H Node address: 59 Node address: 58
05C4H Node address: 61 Node address: 60
05C5H Node address: 63 Node address: 62
Scan Type Code (Hexadecimal)
Unassigned 00H
Bit strobe mode 01H
Polling mode 02H
Polling and strobe 03H
Reserved Other than the above
