Touch Dynamic CP200 - Compact Flash and CMOS Jumper Settings; Power, CPU Frequency, and Voltage Jumper Settings; LCD ID Jumper Settings

1. Compact Flash Master/Slave Setting ◎ Factory Default Setting
Function JP1 (SHORT)
Master
◎1-2
Slave NC
2. CMOS Operation Mode Setting
Function JP5 (SHORT)
CMOS Normal
◎NC
CMOS Reset 1-2
3. Power Mode Setting
Function JP9 (SHORT)
ATX
◎NC
AT 1-2
4. CPU Frequency Setting
Function JP10 (SHORT)
◎FSB 400
1-2,3-4
FSB 533 3-4
5. CPU Voltage Setting
CPU Type JP7 (SHORT) JP8 (SHORT)
Mobile Celeron
1.2 G (1.3V)
NC
3-4, 1-2 (NC)
9-10, 5-6 (NC)
7-8 (NC)
11-12 (NC)
◎P4, Celeron
1- 2, 3-4
5-6, 7-8
9-10, 11-12
NC
6. LCD ID Setting
LVDS JP6 (SHORT) Panel
Number
Resolution
Bits Channel 1-2 3-4 5-6 7-8
0 640 x 480 18 Single SHORT SHORT SHORT SHORT
1 800 x 600 18 Single SHORT SHORT SHORT OPEN
2 1024 x 768 18 Single SHORT SHORT OPEN SHORT
3 1280 x 1024 24 Dual SHORT SHORT OPEN OPEN
4 1024 x 768 24 Single SHORT OPEN SHORT SHORT
5 800 x 600 24 Single SHORT OPEN SHORT OPEN
33
