tousek PULL T24 - Motor

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 19 -
Attention
At force adjustment the valid safety regulations and standards have to be strictly followed !
max. force  100% (factory setting) Motor
 50–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time  0,50s (factory setting) Motor
 0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
speed  100% (factory setting) Motor
 55–100% adjustable [increment 5]: determines the speed of motor.
soft stop way  0,5m (factory setting) Motor
 0–2m adjustable [increment 0,1]: determines the distance of soft run.
soft speed  40% (factory setting) Motor
 10–50% adjustable [increment 5]: determines the speed during soft run.
limit position OPEN  -5 (factory setting) Motor
 0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing barriers). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting  -5 will be saved.
limit position CLOSE  -5 (factory setting) Motor
 0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing barriers). With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting  -5 will be saved.
Motor Connections and adjustments
