tousek PULL T24 - 8 Dimensioned Drawing

- 30 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
We reserve the right to change dimensions and
technical specifications without prior notice.
8. Dimensioned drawing Sliding gate operator PULL T24, -T24speed
• Dimensions in mm
(1) lockable emergency release (euro standard cylinder)
(2) gear wheel
(3) cable entrance
(4) ground plate
(4a) slotted holes (4x) for mounting on foundation
(5) display for programming
PULL -T24 -T24speed
1)
gear wheel Z16M4, r36 Z20M4, r44
2)
gear wheel center 63
3)
gear wheel top 99 107
1
2
5
A B
View B: View A:
306,5
133
63
316
206,5
22
1263,4
gear wheel
1)
gear whell
top
3)
gear wheel
center
2)
3
272
48,5
40
85
52
13,5
4
58,5
4a
309
119,5
