Function
K1 K2
Gate status display
1
Gate in CLOSE-Position 1 0
Gate in OPEN-Position 0 1
2
Gate in CLOSE-Position 0 0
Gate opens or closes 0 1
Gate stopped or fault 1 0
Gate in OPEN-position 1 1
0 = signal contact open, 1= signal contact closed
• You will need for use of adjustments one of the selected adjustements (courtyard-/control l hence
gate status 1 or 2.
Signal lamp
• a signal lamp can be con-
nected to the terminals 10/11
(230V, max. 100W).
Prewarning OPEN (Signal lamp:terminals 10/11) Lights / Lamps
 turned o󰀨
 1–30s adjustable: Before each opening movement the
signal lamp/ ashing light is activated for the adjusted
time.
Prewarning CLOSE (Signal lamp: terminals 10/11)
 turned o󰀨
 1–30s adjustable: Before each closing movement the
signal lamp/ ashing light is activated for the adjusted time.
The following two menu points can only be selected if the menu point additional menu is adjusted to „Courtyard-/Control
lamp“ (hence shown on display).
Courtyard light (Description add. modules

page 22) Lights / Lamps
 turned o󰀨
 5–950 adjustable: at the courtyard lamp output an external lamp can be connected (e.g. garden lamp), which can be
turned on for each opening command for the duration of adjusted time.
Pilot (control) lamp (Description add. modules

page 22) Lights / Lamps
 illuminates when opening/closing: The pilot lamp output is activated during opening- and closing movement.
 blinks slowly / illuminates / blinks: The pilot lamp output is activated as follows: During opening the pilot lamp ashes
slowly. During pause time, in opened position or when the gate stops it is illuminated. During the closing movement it
ashes rapidly. If the gate is closed, the pilot lamp expires
 illuminates in open position: Pilot lamp is illuminated as soon as the gate has reached end position open.
Additional module (Description add. modules

page 22) Lights / Lamps
 yard/control light: the menu points courtyard lamp and control lamp are ready for adjustment (that means if not selected,
these menu points will not be shown on the display)
 status display 1: with the two potential-free signal con-
tacts K1 and K2, the gate end positions (limits) can be
evaluated.
 status display 2: with the two potential-free signal
contacts K1 and K2, the gate end positions (limits), the
gate movement as well as a gate stop outside of the end
positions can be evaluated.
11
10
N
L
Lights / Lamps Connections and adjustments
Warning
• Before connection works please turn o󰀨 the main power switch !
• Safety rules please

page 13 !
