TF5 - Manual
23
3.15 Power supply
The aircraft tug is supplied with energy exclusively via batteries. The system consists of four
12VDC maintenance-free, sealed lead-gel batteries. The batteries are charged via the integra-
ted charger (100-240VAC connection) (see 4.8 Aircraft Towing Charger, page 30).
3.16 Connections
The aircraft tug has various connections. Thefore the operator must be able to identify the
connections shown in the gures below:
3.14 Remote Control
Frequency Range
Baudrate
Operating Voltage
Power Consumption
RF Performance
Safety Class
Working Temperature
Weight (without Battery)
Dimensions (L x W x H)
see Plate
1.200 - 9.600 Baud (Bit/sec)
Battery 7.2V
0 - 100 mA
< 10 mW ERP
IP 65
-20°C to +70°C / -4°F to +158°F
1.000g
247 x 139 x 117 mm / 9,72“ x 5,47“ x 4,60“
Battery Charger Cable Connection for the Remote Control (optional)
