5.10 Towing Ground Support Equipment
Optional OEM accessories can also be used to tow ground support equipment with the aircraft
tug. For this purpose there is a recess for a locking bolt inside the turntable. Before hauling AGE/
GSE, make sure the turntable is locked. The lifting platform must be brought into the upper-
most position against the limit switch.
Note: It is important to note that the position of the nose wheel adapters may
need to be changed for each conguration.
Recess for locking Bolts Locking for the Turntable
ATTENTION! Failure to comply may result in damage to the TowFLEXX unit.
5.9 Nosewheel approach configurations
The aircraft tug oers four dierent ways in which the nose wheel of the aircraft can be appro-
ached. The illustration below shows you the dierent options.
Mode Selection
Turning Direction
11
22
33
