46
1. Push both battery disconnect switches (e-Stops) and secure the tug against unintended
movement.
2. Remove the winch cover.
3. Disconnect all connections to the e-Cube. For safety reasons, start with the main power
supply (blue connector).
4. Now the e-Cube can be pulled out.
5. Do steps 1-3 in reverse order.
7.8 e-Cube Replacement
The e-Cube of the TowFLEXX TF5 can be exchanged very quickly. This can happen in case of
technical problems or when updating the electronic components (new security features, add-
ons, etc.).
7.9 Turntable Gate ReAlignment
It is possible that the gate will lose its correct alignment after a certain period of use. With these
easy to follow steps it can be realigned within minutes.
Just a few steps are needed to remove the e-Cube
Position of the e-Cube
Tip: We recommend that you perform this step with at least two people.
Loosen the four bolts on the lower right side of the turntable.
