42
6.2 Plan of Fuses
Batteries
Tires
Frame and Chassis
Turntable
Lifting Platform
Limiter Switch
(if installed)
F1
F2
F3
F5
F6
F7
F8
F9
F10
350A
350A
10A
10A
10A
3A
10A
10A
250A
Control Unit U1
Control Unit U2
Key Switch
DC-DC Converter
Supply Auxiliary
Battery Charger
CAN Controller
CAN Controller
CAN Controller
Control Unit U6
Drive Motor 1
Drive Motor 2
Ignition Switch
Current Transformer 48V/24V
RC Replacement Battery
Turntable Motor
Drive Chain
Funcional Tests
Lighting
min. 1 recharge a Month
Check the Battery-Plug for Damage, Function and
tight Fit
Check Drive Wheels for Wear and Damage
Tighten the Wheel Nuts of the Drive Wheels (220Nm)
Check Castor Wheels on Wear and Damages
Visual Inspection
Check Screws for tight Fit
Check Readability and Quality of Labels
Visual Inspection and Function Check
Check Steel Cable and Grease if necessary
Check if the steel cable is still correctly winded
on the winch drum
Check if it triggers correctly
Lubricate Drive chain
Visual Inspection and Tension Check
Testing all Commands on the Remote Control
Driving Control
Testing the Brakes without Load
Lubricate wheel ange rollers
Check Turntable Gate Function, adjust if necessary
Apply Grease on the Turntable Gate
Visual inspection Turntable Motor and Gear
Lighting function Check
10h or
25h or
50h or
25h or
50h or
25h or
25h or
25h or
25h or
10h or
10h or
25h or
25h or
50h or
25h or
25h or
25h or
25h or
25h or
25h or
25h or
50h or
monthly
anually
anually
half-yearly
anually
anually
anually
anually
anually
every 3 month
monthly
half-yearly
half-yearly
anually
half-yearly
anually
anually
half-yearly
half-yearly
half-yearly
half-yearly
anually
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Assembly
Designation
Persevering Activities
Amperage Assigned to
Interval
Responsible for
To Next Page
