TF5 - Manual
49
8. Packaging and Transport
8.1 Unloading the Aircraft tug
In order to provide the best possible protection for the aircraft tug during transport, it is secu-
red in a reusable wooden transport box. The following steps are necessary to safely drive the
tug out of the transport box.
To remove the cover, you must loosen the marked bolts
around the cover.
Before you can lift the cover and open the ight case, remove
the screws on the front panel.
Afterwards the panel / ramp can be folded down.
Lift up the cover an put it aside.
ATTENTION! We recommend to do this with two
persons, otherwise there is a risk of injury.
Note: Use the supplied bit to remove the bolts.
Unscrew the crossbars from both sides.
