10. appendix
10.1 Error Codes
The TF5 has various safety features that help to prevent damages or injuries in emergency
situations. Whenever one of these features is activated the user gets a notication on the screen
of the remote control showing an error code. The following list shows the most common codes
that can appear in everyday use.
No SPS present, Internal Error Code of Drive Systems
No SPS present, Internal Error Code of Drive Systems
No SPS present, Internal Error Code of Drive Systems
No SPS present, Internal Error Code of Drive Systems
No SPS present, Internal Error Code of Drive Systems
Emergency Stop pressed
Remote control not in neutral state
No connection to Remote Control Receiver/Transmitter
Joystick Error K1A/B
Joystick Error K3A/B
Emergency Stop Error
Release of Emergency Stop acknowledged
External Emergency Stop (only on units with EE-Certication)
Recharging: No Movement possible
No CAN Bus Signal ACE2 2µ Master Motor right
No CAN Bus Signal ACE2 2µ Slave Motor right
No CAN Bus Signal ACE2 2µ Master Motor left
No CAN Bus Signal ACE2 2µ Slave Motor left
No CAN Bus Signal Remote Control Receiver
No CAN Bus Signal ACE2 Combi 2µ Master
No CAN Bus Signal ACE2 Combi 2µ Slave
SPS: Voltage low
SPS: Voltage low
SPS: Voltage low
SPS: Voltage low
Turntable Sync: Dierence between Drive and Turntable to high
Turntable Sync: Encoder wrong Direction
Turntable Sync: Unreliable state
Turntable Sync: Target value to high
Turntable Sync: Parameter Error
Temperature Motor right 20°C over Limit
Temperature Drive System right 5°C over Limit
No Feedback Brake right
No Feedback Motor Encoder right
Temperature Motor left 20°C over Limit
Temperature Drive System left 5°C over Limit
No Feedback Brake left
No Feedback Motor Encoder left
04 - 42
04 - 60
04 - 96
04 - C9
16 - 06
1 - 1
1 - 2
1 - 3
1 - 5
1 - 6
1 - 7
1 - 11
1 - 12
1 - 20
2 - 8
2 - 9
2 - 10
2 - 11
2 - 16
2 - 24
2 - 25
3 - 1
3 - 2
3 - 3
3 - 4
3 - 10
3 - 11
3 - 12
3 - 13
3 - 14
3 - 22
3 - 23
3 - 24
3 - 25
3 - 26
3 - 27
3 - 28
3 - 29
Code Explanation
