26
Forward / Backward
Traction Power
100%
60%
30%
Driving Mode
Inverted
Normal
Turntable Mode
Only Turntable*
Tug & Turntable*
O
Light On / O
Horn On / O
E-Stop
Lifting Platform Up
Lifting Platform Down
Line Assistant
Brakes behavior
pickup / release*
colored
contoured
(if available)
* By default, the TowFLEXX TF5 brakes will be released
when the platform is lifted or lowered and can move
slightly, this allows for movement of the landing gear
and will avoid any unnecessary stress to the nose
landing gear whilst capturing or unloading the aircraft
On ramps or slopes it would be advisable to engage
the braking system, so the brakes remain on and locked
to prevent the Tug from rolling away when picking up
or lowering. (From Software Version 2.3.3 otherwise
unassigned)
Stops The Aircraft tug Imme-
diately; If this Switch is
activated, an error will appear
on the Status Display
shows normal
driving mode
shows inverted
driving mode
*if this mode is activated, the
tug cannot be moved
forward and backward
See Section 5.8
On
O
Remain Engaged
Disengage
Speed
Fast
Slow
GREEN = Default Position
BLACK
= Selection
Status Display Left / Right
Battery
Status
RC
Traction
Power
Horn
Light
Lifting Plattform
Direction
Turntable
Brake
Turntable
Mode
Speed
Direction Indicator Line Assistant
Battery
Status
(Tug)
Connection
Status
Assigned
Channel
Status Display Errorcode Example
