1-11
REGULATORS SYSTEM COMPONENTS
LPG Cutoff Device
The solenoid valve for slow path control is integrated with the regulator. The solenoid valve is opened and closed
according to the engine speed, starter signal etc. detected by means of engine ECU. When the ignition switch is ON,
with the engine not running, the valve is closed not to flow LPG to the adapter.
Ignition
switch
ST
ON
AM
EFI
main
relay
Battery
LPG
Solenoid
relay
Slow
solenoid
Main
solenoid
Engine ECU
Gasoline
Starter
relay
Starter
motor
Igniter
LPG-
Gasoline
switch
LPG
01.book 11 ページ ２００７年２月２２日 木曜日 午後４時４６分
LPG Device for 4Y-E Engine
Section 1.3.1

Toyota 8FDU32 Specifications

General

Model	8FDU32
Fuel Type	Diesel
Transmission	Automatic
Tire Type	Pneumatic
Rated Capacity	3200 kg
Load Capacity	3200 kg
Load Center	500 mm
Lift Height	3000 mm
Mast Type	Triple
Overall Length	2470 mm
Overall Width	1150 mm
Overall Height	2070 mm
