Chapter 11
Specify Your Network Settings
Subnet Mask of Site B.
7 ) Select the Key Exchange Method for the policy. We select
Auto(IKE) here.
8 ) Enter the Pre-Shared Key for IKE authentication. Then
keep Perfect Forward Secrecy enabled.
Note:
Make sure Site A and Site B use the same key.
9 ) Leave the Advanced Settings as default value. Then click
OK to save.
3. Configuration on Site B (remote network). Refer to step 2
configuration on Site A and make sure that Site A and Site B
use the same pre-shared keys and Perfect Forward Secrecy
settings.
4. The Status column will change to Up if the VPN connection
has been set up successfully.
5. Check the VPN connection. You can ping site B’ LAN IP from
your computer to verify that the IPSec VPN connection is set
up correctly.
Tips:
To check the VPN connection, you can do the following.
a . On the host in Site A, press [Windows Logo] + [R] to open
Run dialog. Input “cmd” and hit OK.
b . In the CLI window, type in “ping 192.168.2.x” (“192.168.2.x”
can be IP address of any host in Site B). Then press [Enter].
