TP-Link TD-W8901G Advanced Troubleshooting Guide

10 / 15
Q4. What can I do if I cannot access the web-based configuration page?
1) Configure your computer’s IP Address (TCP/IP settings);
For Windows XP OS
Go to Start > Control Panel, you
will then see the following page.
Click Network Connections
Click Network and
Internet Connections
Click Properties
Right-click Local
Area Connection

TP-Link TD-W8901G Specifications

General

Wireless Speed	Up to 54Mbps
Frequency Band	2.4GHz
ADSL Speed	Downstream: up to 24Mbps, Upstream: up to 3.5Mbps
Wireless Standards	IEEE 802.11g, IEEE 802.11b
ADSL Standards	ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.994.1 (G.hs)
Ports	4 x 10/100Mbps LAN, 1 x RJ-11 ADSL
Antenna	1 x Fixed
Security	64/128-bit WEP, WPA
Protocols	TCP/IP, PPPoE, PPPoA, DHCP
Weight	0.6 lbs (273g)
