TP-Link TD-W8901G Advanced Troubleshooting Guide

5 / 15
Note 1
Open a web browser (either of Windows Internet Explorer, Mozilla Firefox, Apple Safari, Google
Chrome, Opera or any other web browser), key in 192.168.1.1 in the address bar and press enter. The
default username and password are both “admin” (all in lower case).
Refer to the following link for more details: http://www.tp-link.com/support/showfaq.asp?id=87
Note 2
1、 Go to Quick Start, select the correct connection type (PPPoE/PPPoA or the others), and then
enter your local VPI/VCI value and PPP username\password (provided by your ISP), click Save;
Refer to the Quick Installation Guide or http://www.tp-link.com/support/showfaq.asp?id=204 for
more details;
2、 Disable any firewall\wireless MAC filtering\wireless security in the configuration page;
Please refer to the User Guide or Resolution 5 for more details.

TP-Link TD-W8901G Specifications

General

Wireless Speed	Up to 54Mbps
Frequency Band	2.4GHz
ADSL Speed	Downstream: up to 24Mbps, Upstream: up to 3.5Mbps
Wireless Standards	IEEE 802.11g, IEEE 802.11b
ADSL Standards	ITU-T G.992.1 (G.dmt), ITU-T G.992.2 (G.lite), ITU-T G.994.1 (G.hs)
Ports	4 x 10/100Mbps LAN, 1 x RJ-11 ADSL
Antenna	1 x Fixed
Security	64/128-bit WEP, WPA
Protocols	TCP/IP, PPPoE, PPPoA, DHCP
Weight	0.6 lbs (273g)
