TD-W8910G 54M Wireless ADSL2+ Router User Guide
65
threshold size, the RTS/CTS mechanism will not be enabled. The Router sends Request to
Send (RTS) frames to a particular receiving station and negotiates the sending of a data
frame. After receiving an RTS, the wireless station responds with a Clear to Send (CTS)
frame to acknowledge the right to begin transmission. In most cases, keep its default value
of 2347.
¾ DTIM Interval: This value, between 1 and 255, indicates the interval of the Delivery Traffic
Indication Message (DTIM). A DTIM field is a countdown field informing clients of the next
window for listening to broadcast and multicast messages. When the Router has buffered
broadcast or multicast messages for associated clients, it sends the next DTIM with a DTIM
Interval value. Its clients hear the beacons and awaken to receive the broadcast and
multicast messages. The default value is 1.
¾ Beacon Interval: Enter a value between 20-1000 milliseconds. The Beacon Interval value
indicates the frequency interval of the beacon. A beacon is a packet broadcast by the Router
to synchronize the wireless network. The default value is 100.
¾ Mode: In the drop-down list you can select “54Mbps (802.11g)” or “11Mbps (802.11b)”.
"54Mbps (802.11g)", which allows both 802.11g and 802.11b wireless stations to connect to
the Router.
5.5.5 Wireless – Statistics
Choose “Wireless”Æ”Statistics”, you will see the screen of Wireless-Statistics setting shown as
below.
Figure 5-61
This page shows authenticated wireless stations and their status.
¾ BSSID: Displays the connected wireless station's MAC address.
¾ Associated: Displays whether the wireless station has associated with the access point.
¾ Authorized: Displays the information of Authentication.
