TD-W9980 N600 Wireless Dual Band Gigabit VDSL2 Modem Router User Guide
67
Figure 4-54
 MAC Address: The connected wireless station's MAC address
 Current Status: The connected wireless station's running status, one of STA-AUTH/
STA-ASSOC/ STA-JOINED/ WPA/ WPA-PSK/ WPA2/ WPA2-PSK/ AP-UP/ AP-DOWN/ Disconnected
 Received Packets: Packets received by the station
 Sent Packets: Packets sent by the station
To update this page and to show the current connected wireless stations, click on the Refresh
button.
4.10 Guest Network
There are two submenus under the Guest Network menu: Basic Settings and Guest Network
Status. Click any of them, and you will be able to scan or configure the corresponding function.
The detailed explanations for each submenu are provided below.
4.10.1 Basic Settings
Choose menu “Guest Network”“Basic Settings”, and you will see the screen as shown in
Figure 4-55. This feature allows you to create a separate netw
ork for your guests without allowing
them to access your main network and the computers connected to
it.

TP-Link TD-W9980 Specifications

General

Frequency	2.4GHz and 5GHz
Security	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Wireless Standard	802.11a/b/g/n
Ports	4 x 10/100/1000 Mbps LAN
USB Ports	2 x USB 2.0
Weight	500 g
Antenna	3 x external detachable antennas
