Wireless: Connect wirelessly by using the SSID (network name) and Wireless Password
printed on the product label at the bottom of the router.
3. To access the configuration utility, open a web-browser and type the default address
http://tplinkmodem.net
in the address field of the browser.
Figure 3-8 Login the router
4. After a moment, a login window will appear. Enter admin for the User Name and Password,
both in lower case letters. Then click the Login button or press the Enter key.
Figure 3-9 Login Windows
Note:
If the above screen does not pop-up, it means that your Web-browser has been set to a
proxy. Go to Tools > Internet Options > Connections > LAN Settings, in the screen that
appears, cancel the Using Proxy checkbox, and click OK to finish it.
5. Go to Working Mode page, choose Standard Wireless Router and click Save.
Figure 3-10 Working Mode
