TR-Electronic LP-38 - Connection; Bus Termination; Identifier (MAC-ID); Baud Rate

Printed in the Federal Republic of Germany  TR-Electronic GmbH 2003, All Rights Reserved
02/13/2017 TR - ELA - TI - GB - 0040 - 06 Page 13 of 22
5.1 Connection
The pin assignments with view onto the switches are attached in the rear of this
document.
For the supply shielded cables with twisted core pairs with min. 0.5 mm
2
have
to be used !
5.2 Bus termination
If the measuring system is the last slave in the CAN segment, the bus is to be
terminated with an external bus terminal resistance of 120 ohms.
5.3 Identifier (MAC-ID)
The identifier (measuring system address) 0 – 63 is adjusted via rotary switches. The
adjusted address may be assigned only once in the CAN bus.
5.4 Baud rate
The baud rate is adjusted via rotary switches.
Following baud rates are possible:
● 125 kbit/s
● 250 kbit/s
● 500 kbit/s
