6.1.4 Classes
The communication objects are divided into classes. The measuring system supports
the following classes:
Object Class
Number of instances
01h: Identity
1
02h: Message Router
1
03h: DeviceNet
1
05h: Connection
2
04h: Assembly
1
0Fh: Parameter
6
6.1.5 I/O Instance (polled IO)
Input Instance
Number
Name
1
Position value
Input Data Format
Instance
Byte
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
1
0
Low Byte Position value
1
.
2
High Byte Position value
3
Magnet number = 0
4
Low Byte Position value
5
.
6
High Byte Position value
7
Magnet number = 1
.
.
.
.
.
.
.
.
60
Low Byte Position value
61
.
62
High Byte Position value
63
Magnet number = 15
The number of used input bytes corresponds to the number of magnets multiplied with
four.
