7.3.4 Adjust Absolute Value
Danger of physical injury and damage to property due to an actual value
jump during execution of the adjustment function!
The adjustment function should only be executed when the measuring
system is stationary, or the resulting actual value jump must be permitted
by both the program and the application!
Instance 4, r/w
With the adjustment function, the measuring system is set to the desired absolute
position value. The adjustment is executed with the first magnet. The positions of the
other magnets refer to the position of the first magnet.
Is the adjustment performed via the "Parameter Class", the required position value is
set with the "SET-service" and can read as position value with the "GET-service".
0 Adjustment < Total Number of Steps
7.3.5 Number of Magnets
Instance 5, r/w
Each entered magnet needs four input bytes.
