6. Battery Positive Terminal from house batteries
7. DC Ground Bus Terminal to DC Negative bus of DC load center
8. Battery Negative Terminal from house batteries
9. AC Safety Grounding Wires: to AC ground bus of AC load center from AC source ground
10. DC Safety Grounding Bus Terminal (green wire) to engine negative terminal or its DC ground
bus.
11. AC Terminal Block: AC Hot 1 and Neutral from AC Source to AC subpanel
12. Charger Circuit Breaker: 25 amps in the M2012 and M2512, 30 amps in the M3012. Press
breaker to reset.
