Trace Engineering Mariner User Manual

$33(1',;&5()(5(1&(7$%/(6*5$3+6
7UDFH(QJLQHHULQJ&R,QF 7HO 3DUW1XPEHU

WK
6WUHHW1( )D[ 2FWREHU
$UOLQJWRQ:$86$ ZZZWUDFHHQJLQHHULQJFRP
3DJH

(QJOLVKWR0HWULF:LUH&RQ YHUVLRQ&KDUW
AWG Diameter/mm Area/mm²
DC Resistance /
1000ft
14
1.628 2.082 3.14
12
2.052 3.308 1.98
10
2.588 5.261 1.24
8
3.264 8.367 0.778
6
4.115 13.299 0.491
4
5.189 21.147 0.308
2
6.543 33.624 0.194
1
7.348 42.406 0.154
0 (1/0)
8.525 53.482 0.122
00 (2/0)
9.266 67.433 0.0967
000 (3/0)
10.404 85.014 0.0766
0000 (4/0)
11.684 107.219 0.0608
5HFRPPHQGHG%DWWHU\&DEOH6L]H,QIUHHDLU
Inverter
Model #
Typical DC
Am
p
s
1 to 3 feet
One Wa
y
3 to 5 ft
One Way
5 to 10 ft
One Wa
y
M2012 200 Amps 00 0000 0000
M2512 250 Amps 0000 0000 0000
M3012 300 Amps 0000 0000 0000
"Free air" is defined by the NEC as cabling that is not enclosed in conduit or a raceway. Cables
enclosed in raceways or conduits have substantially lower continuous current carrying ability due to
heating factors.
