Traktor Kontrol S8 - Technical Specification

9 Technical Specification
Input/output connectors
A-D: Four pairs of RCA input connectors
MIC 1: One 6.3 mm (1/4") TRS (balanced) microphone input connector
MIC 2: One combo XLR jack or 6.3 mm (1/4") TRS (balanced) microphone connector
BOOTH OUT: Two balanced 6.3 mm (1/4") TRS line out connectors
MAIN OUT: Two balanced XLR outputs
MAIN OUT: Two RCA outputs
PHONES: One stereo 6.3 mm (1/4") headphone output
PHONES: One stereo 3.5 mm (1/8") headphone output
MIDI (IN/OUT) Two 5-pin DIN connectors
GND: One ground terminal screw
K: One Kensington lock slot
USB: One USB 2.0 Type B connector
POWER: One power supply connector
Audio Specifications
Audio Inputs (A/D)
Channels 4 Stereo
Sample Rate 48 kHz
Bit Resolution 24-bit
Converter Cirrus Logic
Technical Specification
TRAKTOR KONTROL S8 - Manual - 261
