16
MS-SVN084A-EN
Electric Heater
The air handlers listed in this manual do not have
factory installed electric heat. Electric heat is available
as an accessory. Please refer to installation instructions
provided with heater kit for the correct installation
procedure.
IImmppoorrttaanntt:: The electrical characteristics of the air
handler, the electric heater kit, and the
supply power should be identical. This air
handler does not have factory installed
electric heater. Electric heater is available
as an accessory. If installing this option, the
only heater kits that can be used are the
series as indicated below.
WWAARRNNIINNGG
WWAARRNNIINNGG!!
IInnssuurree tthhaatt tthhee ffaann iiss rruunnnniinngg dduurriinngg eelleeccttrriicc hheeaatt
ooppeerraattiioonn.. AAllssoo mmaakkee ssuurree tthhaatt tthhee eelleeccttrriicc hheeaatt iiss
ttuurrnneedd ooffff bbeeffoorree tthhee ffaann ttuurrnnss ooffff ttoo aavvooiidd aann
uunnssaaffee ccoonnddiittiioonn..
EElleeccttrriicc HHeeaatteerr KKiittss AAvvaaiillaabbllee
Description Ref. air handler use(ton)
5kW heat strip
2.0/3.0
8kW heat strip
2.0/3.0
10kW heat strip
2.0/3.0/4.0/5.0
15kW heat strip
4.0/5.0
20kW heat strip
4.0/5.0
IInnssttaallllaattiioonn
