8
MS-SVN084A-EN
Fan Performance Data
External static pressure should stay within the
minimum and maximum limits shown in the table
below in order to ensure proper operation of both
cooling, heating, and electric heating operation.
Model 4MXA2024A10NUA
Level
Static Pressure (inches W.C.)
0 0.1 0.15 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Speed 1(CFM) 1030 900 840
— — — — — — — — —
Speed 2(CFM) 1080 960 900 840
— — — — — — — —
Speed 3(CFM) 1220 1120 1060 990 850
— — — — — — —
Speed 4(CFM) 1390 1290 1240 1180 1070 960
— — — — — —
Speed 5(CFM) 1580 1490 1440 1390 1290 1180 1090 970 830
— — —
Speed 6(CFM) 1720 1640 1600 1550 1450 1360 1250 1130 960
— — —
Speed 7(CFM) 1800 1730 1680 1630 1550 1460 1370 1270 1150 970 830
—
Speed 8(CFM) 1850 1820 1790 1740 1660 1580 1500 1410 1340 1200 1080 930
Model 4MXA2036A10NUA
Level
Static Pressure (inches W.C.)
0 0.1 0.15 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Speed 1(CFM)
1150 1050 950 880 - - - - - - - -
Speed 2(CFM)
1200 1100 1000 940 850 - - - - - - -
Speed 3(CFM)
1380 1260 1200 1100 950 - - - - - - -
Speed 4(CFM)
1550 1460 1390 1310 1160 1010 830 - - - - -
Speed 5(CFM)
1710 1650 1600 1560 1480 1400 1310 1210 1080 930 - -
Speed 6(CFM)
1840 1800 1750 1710 1640 1590 1500 1420 1330 1220 1100 960
Speed 7(CFM)
1870 1830 1810 1800 1760 1690 1620 1520 1440 1350 1250 1150
Speed 8(CFM)
1900 1860 1840 1830 1790 1720 1660 1600 1540 1440 1320 1220
PPrroodduucctt IInnttrroodduuccttiioonn
