Trane Technologies 4TXD2060A10NUA - Main Components; General Information

6
MS-SVN084A-EN
Main Components
General Information
Model
Cooling Capacity(ton) Optional Electric Heater (kW)
4MXA2024A10NUA 2.0
5/8/10
4MXA2036A10NUA 3.0
5/8/10
4MXA2048A10NUA 4.0
10/15/20
4MXA2060A10NUA 5.0
10/15/20
Model
Motor @ 230V ~, 60Hz
HP FLA
4MXA2024A10NUA
4MXA2036A10NUA
1/2
2.1
4MXA2048A10NUA
4MXA2060A10NUA
1 3.2
Model
Filter Size - inch (mm)
4MXA2024A10NUA
4MXA2036A10NUA
19.29 x 20.31 x 0.59 (490 x 516 x 15)
4MXA2048A10NUA
4MXA2060A10NUA
20.67 x 20.31 x 0.59 (525 x 516 x 15)
Notes:
• Based upon W/nominal tonnage, dry coil and filter should be installed.
• Use 0.96 as approximate SCFM correction factor for wet coil.
PPrroodduucctt IInnttrroodduuccttiioonn
