14
RT-SVX34V-EN
Figure 5. 60 Hz 27.5-35 tons (YCD high heat)
Figure 6. Rear view showing duct openings for horizontal supply and return, 60 Hz 27.5-35 Tons (YCH high heat)
Notes:
• On horizontal units, the VFD is located between the supply and return ductwork, which makes access limited.
• For combination of horizontal and downflow openings (digit 3 = F or R) see for appropriate downflow dimensions and
for appropriate horizontal dimensions.
Unit Dimensions and Weights
