RT-SVX34V-EN
7
Miscellaneous Options
Digit 17
0 = No Service Valves
A = Service Valves
Discharge service valves are standard and
included in all units.
Digit 18
B = Through the Base Electrical Provision
Digit 19
C = Non-Fused Disconnect Switch w/ External
Handle
Digit 20
D = Factory-Powered 15A GFI Convenience Outlet
and Non-Fused Disconnect Switch w/ External
Handle
Digit 21
E = Field-Powered 15A GFI Convenience Outlet
Digit 22
* = Unused Digit
Digit 23
G = Ventilation Override
Digit 24
H = Hinged Service Access
Digit 25
H = Condenser Louvered Hail Guards
J = Condenser Coil Guards (standard)
Digit 26
0 = None
K = Advanced Control and LonTalk Comm (LCI)
B = Advanced Control and BACnet/Modbus Comm
(BCI)
A = Advanced Control and AirFi Wireless (WCI)
Digit 27
0 = 5kA SCCR
D = High Fault 65kA SCCR Disconnect
5
E = High Fault 65kA SCCR Disconnect w/Powered
Convenience Outlet
5
Digit 28
0 = Standard Drain Pan
M = Stainless Steel Drain Pan
1 = Standard Drain Pan w/ Condensate Overflow
Switch
2 = Stainless Steel Drain Pan w/ Condensate
Overflow Switch
Digit 29 — Efficiency/ Condenser Coil
Options
0 = Standard Efficiency Unit (eStage)
J = Standard Efficiency Unit (eStage) w/ Corrosion
Protected Condenser Coil
K = High Efficiency Unit (eStage)
L = High Efficiency Unit (eStage) w/ Corrosion
Protected Condenser Coil
Digit 30, 31 — Miscellaneous Options
P = Discharge Temperature Sensor
R = Clogged Filter Switch
Digit 32 — Modulating Hot Gas Reheat
Option
T = Modulating Hot Gas Reheat
Digit 33 — Control Expansion Modules
0 = None
A = Symbio 700 XM- 30 Expansion Module
B = Symbio 700 XM- 32 Expansion Module
C = Symbio 700 XM- 30 & XM-32 Expansion
Modules
D = Symbio 700 XM- 30 & XM-30 Expansion
Modules
E = Symbio 700 XM- 32 & XM-32 Expansion
Modules
Model Number Notes
Notes:
1. All voltages are across the line starting only.
2. Electric Heat KW ratings are based upon
voltage ratings of 208/240/480/ 600 V. For a
240 V heater derated to 208 V, the resulting
kW rating decreases from 36 kW to 27 kW,
and from 54 kW to 41 kW. Voltage offerings
are shown in following table (see Table 22, p.
56 for additional information).
3. The service digit for each model number
contains 33 digits; all 33 digits must be
referenced.
4. Ventilation override exhaust mode is not
available for the exhaust fan with fresh air
tracking power exhaust. VOM is available for
the exhaust fan without fresh air tracking
power exhaust.
5. 575 VAC option is 25kA.
Tons
Elec.
Heater
Rated
Volt.
KW
27/
36
41/
54
72 90 108
27.5
to 35
208 x x
240 x x
480 x x x x
600 x x x
40
and
50
208 x
240 x
480 x x x x
600 x x x x
Model Number Description
