20 FAXA-SVX01B-EN
Installation
dimensions
& weights
CONDENSER FANS
HORIZONTAL DISCHARGE
(OPTION)
HUMAN INTERFACE
ACCESS DOOR
UNIT CONTROL PANEL
24 VOLT CONTROL CIRCUIT WIRING ENTRANCE
(CAN ALSO BE RUN THRU-BASE)
MAIN POWER WIRING ENTRANCE
(CAN ALSO BE RUN THRU-
BASE)
MAIN CONDENSER
COIL ACCESS
PANEL (68x36)
REHEAT COMPRESSOR/COIL ACCESS PANEL
(34x36)
MAIN COMPRESSOR ACCESS PANEL
(40x35)
LIFTING HOLES
CONVENIENCE OUTLET (OPTION)
DUAL GAS HEAT ACCESS PANEL
(EACH HEATER HAS SEPARATE PANEL)
(16x23)
GAS CONNECTION–DUAL GAS HEAT
(EACH HEATER HAS SEPARATE GAS CONNECTIONS)
NATURAL GAS 250–400 MBH: Æ.500 NPT INTERNAL
ELECTRIC HEAT POWER WIRING ENTRANCE
(ALSO CAN BE RUN THRU-BASE)
ELECTRIC HEATER ELECTRICAL PANEL (24x30)
-OR-
GAS HEAT PANEL (16x23)
-OR-
FIXED PANEL FOR NO-HEAT OPTION
OR HYDRONIC HEAT INTERFACE OPTION (24x47)
CONDENSATE
DRAIN CONNECTION
EVAP COIL AND
CONDENSATE DRAIN PAN
ACCESS DOOR (18x34)
INLET HOOD
SUPPLY FAN ACCESS DOOR
(33X34)
Exterior features for unit sizes 031 & 040,
without TE wheel
FILTER AND DAMPER ACCESS DOOR
(25x39)
