Figure 10. GEC 0.5 to 1.5 tons (60 Hz) - subbase (LH) extended length
19 3/4"
63"
28"
33"
6"
15"
9 5/8"
3/4"
11 1/4"
3 3/4"
3/4"
TOP VIEW
ISO VIEW
Unit Dimensions
