16
WSHP-SVX022A-EN
Figure 11. GEC 0.5 to 1.5 tons (60 Hz) - cabinet (RH) low height unit
3/4"
3/4"
4"
9 5/8"
10 1/2"
7/8"
4 3/8"
4 7/8"
19 3/8"
21 1/4"
19 7/8"
11 1/4"
22 1/2"
.625 I.D.
DRAIN CONN.
WATER IN
.625 ODS
WATER OUT
.625 ODS
13 7/8"
6 1/4"
RECEPTACLE BOX
PIPE & ELECTRICAL
FIELD HOOK-UP
47 1/4"
5"
15 3/4"
(4) .25 WALL SLEEVE
MOUNTING HOLES
4"
7/8"
34 3/4"
1 3/4"
RETURN AIR OPENING
1 1/4"
6" LONG,
PLASTIC HOSE
PROVIDED FOR
CONDENSATE
CONNECTION
7 3/4"
3 3/8"
2 3/4"
UNIT CONTROLLER
48"
12"
FIELD ADJUSTABLE
BI-DIRECTIONAL GRILLES
SIDE VIEW
BACK VIEW
FRONT VIEW
TOP VIEW
PIPE & ELECTRICAL
FIELD HOOK-UP
BACK OF UNIT
1 1/2"
3/4"
20 1/2"
Unit Dimensions
